Die casting Aluminum Material Integrated LED Lighting ,high lumen brightness led light parts with PCB, Lens choose

Model No： EK-LD06
Match Power： 60W/180W
Contain Accessories： Aluminum Housing,Toughened Glass, Assembly Screws,Lamp Post pole,
Item         :  IP65 LED Street Lighting Housing
Power      :   60W / 180W
Input Voltage   :   AC220 - 240V, 50/60 HZ
Избор на цвят: тъмно сив, светло сив, черен, персонализиран и др
Lifespan  :  ≥50000 Hours

Характеристики на продукта

  • Once powder coating can give 5years guarantee
  • Four size to match differentpower 40w 80w 120w 150w 180w
  • IP66 grade waterproof to protect lighting use seaside
  • IK09 glass grade to use for high standard projects
  • Висококачествени аксесоари 304 винтове от неръждаема стомана
  • 72hours salt spray testing, suit use on seaside road way,
  • High heat dissipation conductive with convolution property
  • Lamp post match : 50/60mm
  • Powder treatment: sandy gray powder painting
  • Surface Color : Dark gray, Light gray & Black and others be customized

Спецификация на продукта

Powder Coating 100w 120w IP66 LED Street Light Housing

EK-LD06

IP66/IP67 , IK09/IK10,

Материал: ADC12 алуминий

Цвят на корпуса: сив, черен,

  1. - Made of ADC12 aluminum Die-casting,
  2. - IP66 waterproof ADC12 Aluminum case,
  3. - surface treated by Spray-painting to Prevent Corrosion and color Persistence,
  4. - High heat dissipation conductive
  5. - Corrosion resistant polyester powder paint 2.0mil thickness,
  6. - Standard colors : Dark gray, Light gray & Black any special can be customized,

Цяла серия и спецификация

Код на моделаHousing Size （mm)Мощност на мача  Lamp Post （mm)  Weigh（Kg)Аксесоари
    EK-LD06(XS)535*200*120  20W-40W 502.9Heatsink body,armoured glass,Waterproof Rubber Ring，304 s/s screws,
EK-LD06(S)590*235*12550W-80W 50/60  3.6
EK-LD06 (M)690*260*130100W-120W  605.8



EK-LD06 (L)693*310*181150W-180W60                8.0
Legend: Std = IP66 IK09 Testing certificates
Материал на корпуса: лят алуминий + бронирано стъкло
Работна температура -40℃~50℃ 20%~90% HR
